Brand: Dauha
Product: NVR4216-4KS3 16CH 1U 2HDDs Lite Network Video Recorder
Access Channel: 16 channels
Network Bandwidth: AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
Resolution: 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF
Decoding Capability: AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps
Video Output: 1 HDMI, 1 VGA Simultaneous? HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous? HDMI: 1920× 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Multi-screen Display: Main Screen: 1/4/8/9/16 Sub Screen: 1/4/8/9/16
Third Party Camera Access: Onvif; RTSP;
Network Protocol: HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; P2P
Mobile Phone Access: iDMSS (iOS); gDMSS (Android)
Interoperability: ONVIF (profile T/profile S/profile G); CGI; SDK
Browser: Chrome; IE9 or above; Firefox
Multi-channel Playback: Up to 8 channels
Record Mode: Priority of record mode: Manual recording > alarm recording > motion detection recording > timed recording
Storage: Local HDD and network
Backup: USB device
Playback Function: 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame; 2. Full screen, backup (cut/file), partially enlarge, audio on/off
General Alarm: Motion detection, privacy masking, video loss, PIR alarm, IPC alarm
Anomaly Alarm: Front-end device going offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly
Intelligent Alarm: N/A
Alarm Linkage: Video recording, snapshot, log, preset, tour
HDD: 1 SATA 2.0 port, up to 8 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB: 1 front USB 2.0 port, 1 rear USB 2.0 port
HDMI: 1
VGA: 1
Network: 1 × RJ-45 (10 or 100 Mbps)
RCA Input: 1
RCA Output: 1
Dimensions: 260 mm × 225 mm × 47.6 mm
weight: 1.38 kg (3.04 lb)
